Zing Prone Size 2 (PB5606) Packages

Description

Zing Prone Size 2 (PB5606)
Fit Individuals from 32 – 60″
Weight Limit: Up to 154 lbs.

The Zing Prone size 2 is a larger version of Zing Prone size 1 and is a single position stander but is one of the few to offer a flat-to-load transfer position at a comfortable height of 31″. Prone positioning from 0–90 degrees including vertical and up to 30 degrees of independent leg abduction.

E0638: Standing frame/table system, one position (e.g. upright, supine or prone stander), any size including pediatric, with or without wheels

The Zing Prone size 2 is a single position stander but is one of the few to offer a flat-to-load transfer position at a comfortable height of 31″. Prone positioning from 0–90 degrees. Up to 30 degrees of independent leg abduction (60 degrees bilateral).

Specs

• Height Range: 32″–60″ / 82–152 cm
• User Weight Limit: 154 lbs / 70 kg
• Transfer Height (Horizontal Position): 31″ / 79 cm
• Center of Hip to Footplate Range (maximum): 34″ / 86 cm (footplates may be inverted as needed)
• Upper Body Support Vertical Adjustment Range: 6″ / 15 cm (7 settings)
• Approximate Equipment Weight (basic unit, minimally equipped): 82 lbs / 37 kg
• Approximate Equipment Weight (fully optioned): 145 lbs / 66 kg
• Frame Footprint (caster-to-caster): 26.75″ x 39.75″ / 68 x 101 cm
• Maximum Dimensions: 28.75″ x 41.75″ / 73 x 106 cm
• Upholstery: Black nylon/neoprene or molded urethane
• Hygienic Covers: Polyurethane Laminate ECO-PUL
• Frame Color Options: Green, Purple, Orange, or White (medium-gloss polyester powder coat)
• Casters & Wheels: 3″ diameter / 8 cm
• Lifting Mechanisms Available: Gas spring; Pow’r Up (electric)
• Lift Options (Gas Spring): Dual control (hand lever), lockout knob
• Positioning Options:
  • Supine: 0–90°
  • Prone-Forward: 0–20° forward
  • Prone Model: 90° (vertical) to 0° (horizontal)
• Leg Abduction: Up to 30° per side
• Foot Straps (length over arch): 10″, 15″, 21″ / 25, 38, 53 cm
• Secure Foot Straps: Available in same lengths as standard foot straps
• Footplate Options (L x W):
  • 7.75″ x 3.25″ / 20 x 8 cm
  • 9.75″ x 4″ / 25 x 10 cm
  • 11.75″ x 5″ / 30 x 13 cm
  • Platform Style: 11.5″ x 16.75″ / 29 x 43 cm
• Multi-Adjustable Footplates: Plantar/Dorsi ±20°, Fore/Aft ±0.75″ (±2 cm), Rotation ±30°
• One-Piece Calf Pad / Leg Rest: 17.5″ x 5.5″ / 44 x 14 cm
• One-Piece Calf Pad Strap (fits circumference): 28″–38″ / 71–97 cm
• Kneepad Depth Range (from seat plane): Tight to +7″ / Tight to +18 cm
• Kneepad Inside Width Options: 3.25″, 4.25″, 5″ / 8, 11, 13 cm
• Kneepad Dimensions (H x W):
  • 3.25″: 4″ x 4″ / 10 x 10 cm
  • 4.25″: 4.5″ x 5″ / 11 x 13 cm
  • 5″: 5″ x 6″ / 13 x 15 cm
• Multi-Adjustable Kneepad Width Range: Tight together to 17.25″ outside-to-outside / Tight to 44 cm
• Multi-Adjustable Kneepad Height Range: Infinite from footplate to pelvic pad
• Calf (Behind Knee) Pad Options: 4.5″ or 5.5″ pads with fore/aft adjustment +3″ / −2″ ( +8 / −5 cm )
• Independent Planar Leg (TT) Pad Sizes: 9″ x 7.5″, 12″ x 7.5″, 15″ x 7.5″ / 23x19, 30x19, 38x19 cm
• TT Pad Strap (fits circumference): 19″ / 48 cm
• Shadow Tray Size (Molded/Acrylic): 21″ x 24″ / 53 x 61 cm
• Shadow Tray Height Range (from hip pivot): +4″ to +7″ / +10 to +18 cm
• Shadow Tray Fore/Aft Range: 0.5″–12.5″ / 1–32 cm
• Swing-Away Tray Height Range: +4″ to +7″ / +10 to +18 cm
• Swing-Away Tray Fore/Aft Range: 4″–16″ / 10–41 cm
• Swing-Away Tray Angle Adjustment: −90° to +90°
• Chest Pad (tray mounted): 3″H x 8″W / 8 x 20 cm
• Elbow (Cutout) Tray Pads – Inside Widths: 9.25″, 11″, 13″ / 23, 28, 33 cm
• Hip Support Pad Size: 4.5″ x 4″ / 11 x 10 cm
• Hip Support Width Ranges: 7″–13″ or 12″–18″ / 18–33 or 30–46 cm
• Hip Support (TT) Width Range: 10″–16″ / 25–41 cm
• Lateral Support Pad Size: 4″ x 6″ / 10 x 15 cm
• Lateral Support Width Ranges (Supine & MPS): 7″–11″ or 9″–13″ (varies by upper body pad width)
• Lateral Supports with Elbow Stops / Arm Rests (Supine & MPS): 10″–17″ or 12″–19″ / 25–43 or 30–48 cm
• Lateral Supports Height Range: 4″ or 8″ (by swapping L/R) / 10 or 20 cm
• Lateral Supports Fore/Aft Range: 1″ / 3 cm
• Pelvic Support Options: Planar or Form-to-Fit (Supine, MPS, TT)
• Upper Body Support Options: Planar or Form-to-Fit (Supine, MPS)
• Positioning / Chest Strap Pad Size: 6″ x 10″ / 15 x 25 cm
• Chest Vests: X-Style (11″ x 9.5″, 14.5″ x 10.5″) and Y-Style (17.5″ x 11.5″, 20.5″ x 12.5″)
• Posterior Head Support Height Range: 1″–10″ / 2.5–25 cm
• Posterior Head Support Depth Range: −3.5″ to +1″ / −9 to +2.5 cm
• Head Support Options: 5″ x 8″, 6″ x 10″, 7″ x 14″
• TT Planar Head Support: 9″ x 10″ / 23 x 25 cm
• Anterior Head Support (Prone Model Only): Dual pads, 3″W x 9″H / 8 x 23 cm

Funding

Funding Resources (Zing Size 2)

• Zing Size 2 Sample LMN (Editable .DOCX)
• Zing Size 2 Sample LMN (PDF Reference)
• Zing Manufacturer Funding Guide
• Write an LMN (JustifyIt)

Insurance coverage may be available for qualifying individuals. Funding typically requires clinical evaluation and supporting documentation from the prescribing provider and therapist.

Product Catalogs

• Zing Product Catalog
• Zing Mini Catalog

Manuals

• Zing Prone Size 2 Assembly Manual
• Instruction Manual for Use

Order Forms: (Ref)

• Zing Prone Size 2 Packages Order Form
• Zing Prone Size 2 Itemized Order Form

Standing Brochures

• Hip Surveillance Guide
• Parents’ Guide to Standing

Videos

• Zing Quick Fit Guide
• Zing Prone
• Featured Option: Lift Mechanisms - Dual Control and Foot Pedal
• Featured Option: Swing-Away Tray
