EasyStand
Zing MPS TT Size 1 Package Deals
Zing MPS TT Size 1 Package Deals
No reviews
Regular price
$7,419.00
Regular price
Sale price
$7,419.00
Shipping details shown at checkout or quoted before order is finalized
✅ Authorized Manufacturer Dealer
✅ Manufacturer Warranty Included
✅ Shipping Quote Required Before Order Finalization
✅ Configuration Support Available
✅ Secure Checkout
✅ Need Help? Call 877-349-4978
Need help choosing? Call 877-349-4978
Couldn't load pickup availability
Desc
The Zing MPS TT Size 1 (PA5520) is a pediatric multi-position standing frame designed for individuals up to 44 inches tall and up to 70 lbs. It supports standing in supine, upright, and prone positions without requiring the user to be transferred in and out of the stander when changing positions.
The Zing MPS TT combines the same multi-position standing capabilities as the Zing MPS with a tilt-table style upper body support system. Its longer, wider single support pad provides combined pelvic and back support, and padded strapping is available for users who do not require maximum positioning support. When more targeted support is needed, many of the same positioning components used on the Zing MPS can also be added to the MPS TT.
For users who need more advanced positioning, the Zing MPS TT offers up to 30 degrees of independent leg abduction per side, allowing the entire leg to abduct without requiring separate readjustment of the foot plates or knee pads. Independent and multi-adjustable foot plates, knee pads, calf pads, and floating hip guides also help accommodate a wide range of positioning needs, including unilateral or bilateral contractures.
The base unit includes a prone position lockout to help prevent unintended movement past vertical, along with an available gas spring lift lockout for added safety during position changes. Dual Control allows caregivers to adjust positions by either foot pedal or hand control.
A multi-adjustable swing-away tray can pivot to either side while remaining attached to the unit, or it can be removed completely for transfers and access. With a transfer height of 32 inches and a highly modular design that supports more than 70 accessories and positioning components, the Zing MPS TT Size 1 can be configured from a simpler standing setup to a more involved pediatric positioning system.
Specs
- Height Range: Up to 44″ / Up to 112 cm
- Weight Limit: 70 lbs / 32 kg
- Transfer Height (Horizontal Position): 32″ / 81 cm
- Center of Pelvic Support to Footplate Range: 7″–22″ / 18–56 cm (footplates may be inverted as needed)
- Upper Body Support Height Range: 4″ / 10 cm
- Kneepad Depth Range: 5″ / 13 cm
- Kneepad Inside Width Options: 2.5″, 3.25″, 4.25″, 5″ / 6, 8, 11, 13 cm
-
Kneepad Dimensions:
- 2.5″: 3.5″ x 4″ / 9 x 10 cm
- 3.25″: 4″ x 4″ / 10 x 10 cm
- 4.25″: 4.5″ x 5″ / 11 x 13 cm
- 5″: 5″ x 6″ / 13 x 15 cm
-
Multi-Adjustable Kneepad Width Range (center-to-center):
- 2.5″ pads: 4″–9″ / 10–23 cm
- 3.25″ pads: 4.5″–9″ / 11–23 cm
- 4.25″ pads: 5″–8″ / 13–20 cm
- 5″ pads: 6″–7″ / 15–18 cm
- Multi-Adjustable Kneepad Height Range: ±0.75″ / 2 cm
- Weight of Basic Unit: 55 lbs / 25 kg
- Frame Footprint (caster-to-caster): 20″ x 28″ / 51 x 71 cm
- Maximum Dimensions: 21.5″ x 29.5″ / 55 x 75 cm
- Upholstery: Black nylon/neoprene or molded urethane
- Hygienic Covers: Polyurethane Laminate ECO-PUL
- Frame Color Options: Green, Purple, Orange, or White
- Casters & Wheels: 3″ diameter / 8 cm
- Lifting Mechanism Available: Gas spring
- Lift Options: Dual control (hand lever), lockout knob
-
Positioning Options:
- Supine: 0–90°
- Prone-Forward: 0–20°
- Vertical Model: 90° fixed position
- Leg Abduction: 30° per side
- Foot Straps – Extra Small (length over arch): 8″ or 10″ / 20 or 25 cm
- Secure Foot Straps: Available in same lengths as standard foot straps
-
Footplate Options (L x W):
- 6″ x 3″ / 15 x 8 cm
- 7.75″ x 3.25″ / 20 x 9 cm
- 9.75″ x 4″ / 25 x 11 cm
- Platform Style: 8″ x 12″ / 20 x 30 cm
- Multi-Adjustable Footplates: Plantar/Dorsi ±20°, Fore/Aft ±0.75″ (±2 cm), Rotation ±30°
- Single Calf Pad / Leg Rest: 4″ x 13.5″ / 10 x 34 cm
- Single Calf Pad Strap (fits circumference): 24″ / 61 cm
- Calf (Behind Knee) Pad Options: 3.5″ x 3.5″ or 4.5″ x 4.5″ with fore/aft adjustment −1″ to +4″ / −2.5 to +10 cm
- Independent Planar Leg (TT) Pad Sizes: 4″ x 6″, 6″ x 6″, 8″ x 6″ / 10x15, 15x15, 20x15 cm
- TT Pad Strap (fits circumference): Up to 15″ / 38 cm
- Shadow Tray Size (Molded/Acrylic): 11″ x 19″ / 28 x 48 cm
- Shadow Tray Height Range: 3″ / 8 cm
- Shadow Tray Fore/Aft Range: 0″–10″ / 0–25 cm
- Swing-Away Tray Size: 11″ x 19″ / 28 x 48 cm
- Swing-Away Tray Height Range: 3″ / 8 cm
- Swing-Away Tray Fore/Aft Range: 4″–9″ / 10–23 cm
- Swing-Away Tray Angle Adjustment: +40° to −90°
- Hip Support Pad Size: 3.5″ x 3.5″ / 9 x 9 cm
- Hip Supports Width Range: 6″–10″ / 15–25 cm
- Lateral Support Pad Size: 3.5″ x 3.5″ / 9 x 9 cm
- Lateral Supports Width Range: 4″–8″ or 7″–11″ / 10–20 or 18–28 cm
- Lateral Supports Height Range: 3.5″ / 9 cm
- Lateral Supports Fore/Aft Range: 1″ / 3 cm
- Pelvic Support Options: Planar or Form-to-Fit, multiple sizes for anterior and posterior support
- Upper Body Support Options: Planar or Form-to-Fit, multiple sizes
- Chest Pad: 3″H x 8″W / 8 x 20 cm
- Chest Strap Pad Size: 5″H x 8″W / 13 x 20 cm
- Chest Strap Fit (approx.): Up to 24″ / 61 cm
- Chest Vests: X-Style and Y-Style available in multiple sizes
- Posterior Head Support Height Range: 8″ / 20 cm
- Posterior Head Support Depth Range: −2.5″ to +1.5″ / −6 to +4 cm
- Anterior Head Support (Prone/Vertical): Face aperture pads, 3″ x 9″ / 8 x 23 cm
- Configurations Available: Supine, MPS (Multi-Positional), TT (Tilt Table), Prone, Vertical
Funding
Funding Resources (Zing Size 1)
Zing Size 1 Sample LMN (Editable .DOCX)
Zing Size 1 Sample LMN (PDF Reference)
Open Zing Size 1 Sample LMN PDF in a New Tab
Insurance coverage may be available for qualifying individuals. Funding typically requires clinical evaluation and supporting documentation from the prescribing provider and therapist.
Catalogs
Zing Product Catalog
Open Zing Product Catalog in a New Tab
Zing Mini Catalog
Open Zing Mini Catalog in a New Tab
Manuals
Zing MPS TT Size 1 Assembly Manual
Open Zing MPS TT Size 1 Assembly Manual in a New Tab
Instructions for Use
Open Instructions for Use in a New Tab
Order Forms
Reference Only: These order forms are provided for configuration review and planning purposes only.
Zing MPS TT Size 1 Packages Order Form
Open Packages Order Form in a New Tab
Zing MPS TT Size 1 Itemized Order Form
Open Itemized Order Form in a New Tab
Resources
Hip Surveillance Guide
Open Hip Surveillance Guide in a New Tab
Parents’ Guide to Standing
Open Parents’ Guide to Standing in a New Tab
Videos
Zing MPS TT Size 1 & 2
Featured Option: Lift Mechanisms – Dual Control and Foot Pedal
Featured Option: Swing-Away Tray
Shipping
This product requires a shipping quote before the order is finalized.
Everyday Mobility USA currently ships to the lower 48 United States only. We do not currently ship to Alaska, Hawaii, U.S. territories, APO/FPO addresses, or international addresses.
Shipping costs and delivery options may vary based on product size, configuration, manufacturer requirements, freight carrier rules, selected accessories, and delivery location.
After you select your options and submit a quote/configuration review request from the cart, our team will review the selected configuration and contact you to confirm shipping, delivery details, and final order information before payment is completed.
Questions before submitting your quote request? Call 877-349-4978 and our team can help.
Warranty
Warranty
Altimate Medical, Inc. extends this limited warranty only to the original purchaser/customer (or supplier non-consumer who does not buy or resell). EasyStand and Zing products are warranted against defects in materials and workmanship as outlined below.
Warranty Coverage
- Steel Frames – 5-year warranty
- Hydraulic Actuator – 2-year warranty
- Gas Spring – 2-year warranty
- Upholstered Components, Plastic Pads, Rubber Parts, Painted Surfaces, Bearings, and Other Parts Not Specifically Identified Above – 90-day warranty
Warranty on Electrical Option Components
- Actuator & Hand Pendant – 2-year warranty
- Control Box & Battery – 90 days
- Battery Charger – 90 days
Warranty Period
The warranty period begins on the original ship date from Altimate Medical. Any product proven to Altimate Medical’s satisfaction to be defective and within the warranty period will be repaired or replaced at Altimate Medical’s option.
Warranty Limitations
Altimate Medical’s sole obligation and your exclusive remedy under this warranty are limited to repair and/or replacement. This warranty does not include any labor charges incurred in replacement parts installation. Freight charges to and from the factory are the responsibility of the consumer or seller. Return freight charges will be prepaid by Altimate Medical for warranty service when requested by Altimate Medical before return. To receive satisfactory warranty service, please write directly to Altimate Medical at the address below. Do not return products without prior authorization.
This warranty does not apply to products subjected to negligence, abuse, misuse, improper operation, improper maintenance, improper storage, or damages beyond normal use. It also does not apply to products modified without Altimate Medical’s written consent, including modifications through the use of unauthorized parts or attachments, or products damaged by repairs using parts not manufactured by Altimate Medical or not complying with original equipment specifications.
Disclaimer
The foregoing warranty is exclusive and in lieu of all other express warranties. Altimate Medical shall not be liable for any consequential or incidental damages whatsoever.
Additional Information
Altimate Medical maintains a policy of continual product improvement and reserves the right to change features, specifications, and prices without prior notice. Check with Altimate Medical for the latest product information.
