EasyStand
Zing MPS Size 2 Package Deals
Zing MPS Size 2 Package Deals
No reviews
Regular price
$8,582.00
Regular price
Sale price
$8,582.00
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Description
The Zing MPS Size 2 is a pediatric multi-position standing frame designed for individuals from 32 to 60 inches tall and up to 154 lbs. It supports standing in supine, upright, and prone positions without requiring the user to be transferred in and out of the stander when changing positions.
The Zing MPS is unique in its ability to pivot in two directions, allowing the unit to move from flat-to-load supine to 20 degrees prone in one motion. This creates added positioning flexibility without the need to flip pads, foot plates, or trays between positions. Tool-free adjustments and removable support components also help simplify setup and everyday use for caregivers.
For users who need more advanced positioning, the Zing MPS offers up to 30 degrees of independent leg abduction per side, allowing the entire leg to abduct without requiring separate readjustment of the foot plates or knee pads. Independent and multi-adjustable foot plates, knee pads, calf pads, and floating hip guides also help accommodate a wide range of positioning needs, including unilateral or bilateral contractures.
The base unit includes a prone position lockout to help prevent unintended movement past vertical, along with an available gas spring lift lockout for added safety during position changes. Dual Control allows caregivers to adjust positions by either foot pedal or hand control.
A multi-adjustable swing-away tray can pivot to either side while remaining attached to the unit, or it can be removed completely for transfers and access. With a highly modular design that supports a wide range of accessories and positioning components, the Zing MPS Size 2 can be configured from a simpler standing setup to a more involved pediatric positioning system.
Specifications
- Height Range: 32″–60″ / 82–152 cm
- User Weight Limit: 154 lbs / 70 kg
- Transfer Height (Horizontal Position): 31″ / 79 cm
- Center of Hip to Footplate Range (Maximum): 34″ / 86 cm (footplates may be inverted as needed)
- Upper Body Support Vertical Adjustment Range: 6″ / 15 cm (7 settings)
- Approximate Equipment Weight (Basic Unit, Minimally Equipped): 82 lbs / 37 kg
- Approximate Equipment Weight (Fully Optioned): 145 lbs / 66 kg
- Frame Footprint (Caster-to-Caster): 26.75″ x 39.75″ / 68 x 101 cm
- Maximum Dimensions: 28.75″ x 41.75″ / 73 x 106 cm
- Upholstery: Black nylon/neoprene or molded urethane
- Hygienic Covers: Polyurethane Laminate ECO-PUL
- Frame Color Options: Green, Purple, Orange, or White (medium-gloss polyester powder coat)
- Casters & Wheels: 3″ diameter / 8 cm
- Lifting Mechanisms Available: Gas Spring; Pow’r Up (electric)
- Lift Options (Gas Spring): Dual control (hand lever), lockout knob
-
Positioning Options:
- Supine: 0–90°
- Prone-Forward: 0–20° forward
- Prone Model: 90° (vertical) to 0° (horizontal)
- Leg Abduction: Up to 30° per side
- Foot Straps (Length Over Arch): 10″, 15″, 21″ / 25, 38, 53 cm
- Secure Foot Straps: Available in same lengths as standard foot straps
-
Footplate Options (L x W):
- 7.75″ x 3.25″ / 20 x 8 cm
- 9.75″ x 4″ / 25 x 10 cm
- 11.75″ x 5″ / 30 x 13 cm
- Platform Style: 11.5″ x 16.75″ / 29 x 43 cm
- Multi-Adjustable Footplates: Plantar/Dorsi ±20°, Fore/Aft ±0.75″ (±2 cm), Rotation ±30°
- One-Piece Calf Pad / Leg Rest: 17.5″ x 5.5″ / 44 x 14 cm
- Calf Pad Strap (Fits Circumference): 28″–38″ / 71–97 cm
- Kneepad Depth Range (from Seat Plane): Tight to +7″ / Tight to +18 cm
- Kneepad Inside Width Options: 3.25″, 4.25″, 5″ / 8, 11, 13 cm
-
Kneepad Dimensions (H x W):
- 3.25″: 4″ x 4″ / 10 x 10 cm
- 4.25″: 4.5″ x 5″ / 11 x 13 cm
- 5″: 5″ x 6″ / 13 x 15 cm
- Multi-Adjustable Kneepad Width Range: Tight together to 17.25″ outside-to-outside / Tight to 44 cm
- Multi-Adjustable Kneepad Height Range: Infinite from footplate to pelvic pad
- Independent Planar Leg (TT) Pad Sizes: 9″ x 7.5″, 12″ x 7.5″, 15″ x 7.5″ / 23x19, 30x19, 38x19 cm
- TT Pad Strap (Fits Circumference): 19″ / 48 cm
- Shadow Tray Size (Molded/Acrylic): 21″ x 24″ / 53 x 61 cm
- Shadow Tray Height Range (from Hip Pivot): +4″ to +7″ / +10 to +18 cm
- Shadow Tray Fore/Aft Range: 0.5″–12.5″ / 1–32 cm
- Swing-Away Tray Height Range: +4″ to +7″ / +10 to +18 cm
- Swing-Away Tray Fore/Aft Range: 4″–16″ / 10–41 cm
- Swing-Away Tray Angle Adjustment: −90° to +90°
- Chest Pad (Tray Mounted): 3″H x 8″W / 8 x 20 cm
- Hip Support Pad Size: 4.5″ x 4″ / 11 x 10 cm
- Hip Support Width Ranges: 7″–13″ or 12″–18″ / 18–33 or 30–46 cm
- Lateral Support Pad Size: 4″ x 6″ / 10 x 15 cm
- Lateral Support Height Range: 4″ or 8″ (by swapping L/R) / 10 or 20 cm
- Lateral Support Fore/Aft Range: 1″ / 3 cm
- Posterior Head Support Height Range: 1″–10″ / 2.5–25 cm
- Posterior Head Support Depth Range: −3.5″ to +1″ / −9 to +2.5 cm
- Anterior Head Support (Prone Model Only): Dual pads, 3″W x 9″H / 8 x 23 cm
- Configurations Available: Supine, MPS, TT (Tilt Table), Prone, Vertical
Funding
Funding Resources (Zing Size 2)
- Zing Size 2 Sample LMN (Editable .DOCX)
- Zing Size 2 Sample LMN (PDF Reference)
- Zing Manufacturer Funding Guide
- Write an LMN (JustifyIt)
Insurance coverage may be available for qualifying individuals. Funding typically requires clinical evaluation and supporting documentation from the prescribing provider and therapist.
Catalogs
Resources
Manuals
Order Forms
Reference Only: These order forms are provided for configuration review and planning purposes only.
Videos
Warranty
Warranty
Altimate Medical, Inc. extends this limited warranty only to the original purchaser/customer (or supplier non-consumer who does not buy or resell). EasyStand and Zing products are warranted against defects in materials and workmanship as outlined below.
Warranty Coverage
- Steel Frames – 5-year warranty
- Hydraulic Actuator – 2-year warranty
- Gas Spring – 2-year warranty
- Upholstered Components, Plastic Pads, Rubber Parts, Painted Surfaces, Bearings, and Other Parts Not Specifically Identified Above – 90-day warranty
Warranty on Electrical Option Components
- Actuator & Hand Pendant – 2-year warranty
- Control Box & Battery – 90 days
- Battery Charger – 90 days
Warranty Period
The warranty period begins on the original ship date from Altimate Medical. Any product proven to Altimate Medical’s satisfaction to be defective and within the warranty period will be repaired or replaced at Altimate Medical’s option.
Warranty Limitations
Altimate Medical’s sole obligation and your exclusive remedy under this warranty are limited to repair and/or replacement. This warranty does not include any labor charges incurred in replacement parts installation. Freight charges to and from the factory are the responsibility of the consumer or seller. Return freight charges will be prepaid by Altimate Medical for warranty service when requested by Altimate Medical before return. To receive satisfactory warranty service, please write directly to Altimate Medical at the address below. Do not return products without prior authorization.
This warranty does not apply to products subjected to negligence, abuse, misuse, improper operation, improper maintenance, improper storage, or damages beyond normal use. It also does not apply to products modified without Altimate Medical’s written consent, including modifications through the use of unauthorized parts or attachments, or products damaged by repairs using parts not manufactured by Altimate Medical or not complying with original equipment specifications.
Disclaimer
The foregoing warranty is exclusive and in lieu of all other express warranties. Altimate Medical shall not be liable for any consequential or incidental damages whatsoever.
Additional Information
Altimate Medical maintains a policy of continual product improvement and reserves the right to change features, specifications, and prices without prior notice. Check with Altimate Medical for the latest product information.
