Zing MPS Size 1 Packages (PA5520)

Description

Fits Individuals Up to 44″
Weight Limit: Up to 70 lbs.

The Zing MPS is the only multi-position stander that pivots two directions, allowing the unit to go from flat-to-load supine to 20 degrees prone in one motion. There is no need to transfer the user in and out, flip pads, foot plates and trays. This ability provides a therapeutic opportunity not possible with other standing frames. It is also one of the few standers that provides the option of up to 30 degrees of independent leg abduction.

E0641: Standing frame/table system, multi-position (e.g. three-way stander), any size including pediatric, with or without wheels

The Zing MPS Size 1 is the smaller version of the Zing MPS Size 2. The Zing MPS provides a new therapeutic opportunity to stand in supine, upright, and prone without having to transfer the child in and out of the stander to switch between positions. There’s no need to flip pads, foot plates, or trays to change positions. Tool-free adjustments and/or removal of support and positioning components adds to the ease of use.

Independent Leg Abduction
The Zing MPS offers 30 degrees of independent leg abduction per side (60 degrees bilaterally). A simple knob allows the entire leg to abduct up to 30 degrees, with no need to re-adjust the foot plates or knee pads.

Unique Lift Mechanisms
The base unit includes a prone position lockout to help prevent inadvertently going past vertical. A gas spring lift lockout is available to help prevent inadvertent position changes. Dual Control enables position changes by foot pedal or hand control.

Swing-away Tray
The multi-adjustable tray can swing either direction while remaining attached to the unit, or it can be removed completely. When swung away but still attached on one side, it stays close and within reach once a transfer is completed. The transfer height of the Zing MPS Size 1 is 31 inches.

Remarkably Modular
With 75 support and positioning components/accessories, the Zing MPS can be configured as a simple stander or built out for more complex needs. Independent and multi-adjustable foot plates, knee pads, calf pads, and floating hip guides allow accommodation for unilateral or bilateral contractures.

Specs

• Height Range: Up to 44″ / Up to 112 cm
• Weight Limit: 70 lbs / 32 kg
• Transfer Height (Horizontal Position): 32″ / 81 cm
• Center of Pelvic Support to Footplate Range: 7″–22″ / 18–56 cm (footplates may be inverted as needed)
• Upper Body Support Height Range: 4″ / 10 cm
• Kneepad Depth Range: 5″ / 13 cm
• Kneepad Inside Width Options: 2.5″, 3.25″, 4.25″, 5″ / 6, 8, 11, 13 cm
• Kneepad Dimensions:
  • 2.5″: 3.5″ x 4″ / 9 x 10 cm
  • 3.25″: 4″ x 4″ / 10 x 10 cm
  • 4.25″: 4.5″ x 5″ / 11 x 13 cm
  • 5″: 5″ x 6″ / 13 x 15 cm
• Multi-Adjustable Kneepad Width Range (center-to-center):
  • 2.5″ pads: 4″–9″ / 10–23 cm
  • 3.25″ pads: 4.5″–9″ / 11–23 cm
  • 4.25″ pads: 5″–8″ / 13–20 cm
  • 5″ pads: 6″–7″ / 15–18 cm
• Multi-Adjustable Kneepad Height Range: ±0.75″ / 2 cm
• Weight of Basic Unit: 55 lbs / 25 kg
• Frame Footprint (caster-to-caster): 20″ x 28″ / 51 x 71 cm
• Maximum Dimensions: 21.5″ x 29.5″ / 55 x 75 cm
• Upholstery: Black nylon/neoprene or molded urethane
• Hygienic Covers: Polyurethane Laminate ECO-PUL
• Frame Color Options: Green, Purple, Orange, or White
• Casters & Wheels: 3″ diameter / 8 cm
• Lifting Mechanism Available: Gas spring
• Lift Options: Dual control (hand lever), lockout knob
• Positioning Options:
  • Supine: 0–90°
  • Prone-Forward: 0–20°
  • Vertical: 90° fixed position
• Leg Abduction: 30° per side
• Foot Straps – Extra Small (length over arch): 8″ or 10″ / 20 or 25 cm
• Secure Foot Straps: Same lengths as standard foot straps
• Footplate Options (L x W):
  • 6″ x 3″ / 15 x 8 cm
  • 7.75″ x 3.25″ / 20 x 9 cm
  • 9.75″ x 4″ / 25 x 11 cm
  • Platform style: 8″ x 12″ / 20 x 30 cm
• Multi-Adjustable Footplates: Plantar/Dorsi ±20°, Fore/Aft ±0.75″ (±2 cm), Rotation ±30°
• Single Calf Pad / Leg Rest: 4″ x 13.5″ / 10 x 34 cm
• Calf Pad Strap (fits circumference): Up to 24″ / 61 cm
• Independent Planar Leg (TT) Pad Sizes: 4″x6″, 6″x6″, 8″x6″ / 10x15, 15x15, 20x15 cm
• TT Pad Strap (fits circumference): Up to 15″ / 38 cm
• Shadow Tray Size (Molded/Acrylic): 11″ x 19″ / 28 x 48 cm
• Shadow Tray Height Range: 3″ / 8 cm
• Shadow Tray Fore/Aft Range: 0″–10″ / 0–25 cm
• Swing-Away Tray Size: 11″ x 19″ / 28 x 48 cm
• Swing-Away Tray Height Range: 3″ / 8 cm
• Swing-Away Tray Fore/Aft Range: 4″–9″ / 10–23 cm
• Swing-Away Tray Angle Adjustment: +40° to −90°
• Hip Support Pad Size: 3.5″ x 3.5″ / 9 x 9 cm
• Hip Supports Width Range: 6″–10″ / 15–25 cm
• Lateral Support Pad Size: 3.5″ x 3.5″ / 9 x 9 cm
• Lateral Supports Width Range: 7″–11″ / 18–28 cm
• Lateral Supports Height Range: 3.5″ / 9 cm
• Lateral Supports Fore/Aft Range: 1″ / 3 cm
• Pelvic Support Options: Planar or Form-to-Fit, multiple sizes for anterior and posterior support
• Chest Pad: 3″H x 8″W / 8 x 20 cm
• Chest Strap Pad Size: 5″H x 8″W / 13 x 20 cm
• Chest Strap Fit (approx.): Up to 24″ / 61 cm
• Posterior Head Support Height Range: 8″ / 20 cm
• Head Support Depth Range: −2.5″ to +1.5″ / −6 to +4 cm
• Configurations Available: Supine, MPS (Multi-Positional), TT (Tilt Table), Prone, Vertical
