Merits Health Atlantis Heavy Duty Power Wheelchair
Merits Health Atlantis Heavy Duty Power Wheelchair
✅ Authorized Manufacturer Dealer
✅ Manufacturer Warranty Included
✅ Free Lower 48 Shipping on Eligible Products
✅ Monthly Payment Options Available
✅ Secure Checkout
✅ Need Help? Call 877-349-4978
Need help choosing? Call 877-349-4978
Couldn't load pickup availability

Description
The Merits Health Atlantis P710A is a super heavy-duty rear-wheel-drive power wheelchair designed for bariatric users and more complex rehabilitation needs where strength, stability, and dependable daily performance matter most. Built as a true Group 2 powerbase, it delivers controlled handling and strong support for both indoor and outdoor mobility.
Its reinforced frame is supported by four seat posts for added structural integrity and long-term durability. An extra-wide seat and extra-high backrest are designed to better support bariatric users, while high-power in-line motors help the Atlantis negotiate 10° uphill ramps with greater confidence.
With a tight 31.5-inch turning radius, large 12-inch pneumatic drive wheels, and a driving range of up to 32 miles per charge, the Atlantis P710A offers a strong balance of maneuverability and heavy-duty capability. Batteries are included, so it arrives ready for dependable everyday use.
Features
- Super heavy-duty power wheelchair with 600 lb. weight capacity
- Reinforced frame with four seat posts for exceptional stability and durability
- Extra-wide seat and extra-high backrest for bariatric comfort
- Super high-power in-line motors for climbing up to 10° gradients
- Rear-wheel-drive (RWD) powerbase for predictable, stable handling
- 31.5" turning radius for improved maneuverability
- Large pneumatic tires for a smoother ride over uneven surfaces
Specifications
- Product Number: P710A
- Weight Capacity: 600 lbs
- Drive Train: Rear-Wheel Drive (RWD)
- Seat Type: Captain
- Seat Width: 24.5"
- Seat Depth: 20"
- Backrest Height: 21.25"
- Seat-to-Floor Height: 22" – 23"
- Overall Length: 33"
- Overall Width: 32"
- Overall Height: 41.5"
- Turning Radius: 31.5"
- Ground Clearance: 2.75"
- Total Weight: 304 lbs
- Weight of Heaviest Piece: 167 lbs
- Maximum Speed: 5 mph
- Range Per Charge: Up to 32 miles
- Motor: DC 24V / 300W
- Controller: Dynamic LiNX
- Batteries: (2 Included) 75Ah, M24 AGM
- Charger: 6A off-board
- Maximum Gradient: 10°
- Front Wheels: 9" pneumatic
- Drive Wheels: 12" pneumatic
- Rear Wheels: 3" anti-tippers
- HCPCS Codes: K0826 / K0827
- Color Options: Candy Apple Red, Metallic Blue
Manuals
View or download the official Merits Health Atlantis P710A owner’s manual below.
Download Atlantis Owner’s Manual (PDF)
PC Lite
Download Precision Comfort Lite Guide (PDF)
PC Gel
Shipping
Free standard shipping is included for this product when shipped within the lower 48 United States.
Everyday Mobility USA currently ships to the lower 48 United States only. We do not currently ship to Alaska, Hawaii, U.S. territories, APO/FPO addresses, or international addresses.
Most eligible orders are processed within 1–3 business days after order confirmation. Estimated delivery is typically 5–10 business days after processing, depending on the product, manufacturer, carrier, and delivery location.
Some larger mobility products may ship by freight carrier, and the carrier may contact you to schedule delivery. Delivery services such as liftgate, residential, inside, or white-glove delivery may vary by product.
Questions before ordering? Call 877-349-4978 and our team can help confirm delivery details.
Warranty
Merits Health Warranty
Merits Health Products, Inc. warrants its products against defects in materials or workmanship from the original date of consumer purchase. Warranty service is subject to inspection by an authorized Merits representative.
5-Year Warranty
- Base Frame
- Seatbelt
18-Month Warranty
- Joystick / Power Module / Controller
- Motor / Gearbox / Brake Assembly
- Electrical Harnesses & Circuit Boards
- Angle Sensor
- Charger & Transaxle
- PC Cushion / Back / Positioning Accessories
13-Month Warranty
- Seat Post / Mount & Metal Seat Frame
- Power Seat Actuator
- Caster Beam & Caster Forks
- Joystick Mounting Bracket
- Anti-Tipper Assembly
- 31Ah or Larger Batteries
- Powered Footplate
- Armrest Bracket (metal part only)
6-Month Warranty
- Bearings / Bushings
- Front Riggings
- Non-Powered Footplate
- PC Cover
- Swivel Seat Mechanism
- Merits-Supplied Batteries Under 31Ah
Pilot Staircase
- 5 Years: Motor Gear Box, Over Speed Governor (OSG), Curved / Straight / Hinge Rails
- 2 Years: Non-Wear Components, Circuit Boards, Fasteners, Electrical Harnesses & Switches
Not Covered
Tires & tubes; fuses & bulbs; battery cases; plastic/rubber parts; motor brushes; brake pads; upholstery; and painted surfaces, including shrouds and fenders.
Warranty is void for: acts of nature; lost or stolen units; commercial use; neglect, improper operation or lack of maintenance; unauthorized alterations/service; or removed/defaced serial numbers.
Additional Terms
Parts purchased outside the warranty period have 90 days to report manufacturing defects. Merits may replace warranted parts at its discretion for the original purchaser. Labor, service calls, transportation, freight, and other installation-related charges are the responsibility of the consumer or dealer.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
